Facades / roof glazing

TENTAL 60 MT

Feature Cap

THE CIRCULAR FACADE

Characteristics

The TENTAL 60 MT curtain wall is the new aluminium facade for designing building envelopes with multiple creative options, large glazing units and the lowest environmental impact. It’s an extensive range of solutions, giving as much creative freedom as possible when designing a facade.

TENTAL 60 MT allows modular curtain wall designs with extra large and heavy glazing units to enable maximum transparency with a minimal sightline.

TENTAL 60 MT is a mullion – transom construction with the benefits to use the same system for both façade and sloped glazing and is a mullion drained construction.

Using Hydro CIRCAL®, an alloy made with a minimum of 75% recycled end-of-life aluminium (post-consumer scrap), allows tons of scrap that would otherwise become solid waste to be reintroduced into the system. TENTAL’s thermal break elements are made from recycled xPET, a material that gives a second life to used plastic drinks bottles.

The TENTAL 60 MT curtain wall is the perfect solution for current needs in terms of design and sustainability in the building industry.



Key features of the TENTAL 60 MT curtain walling

  • Standard or high insulation levels
  • Mullion drained
  • Anti-burglary - RC2 / RC3
  • Compatible with a full range of current window, door and sliding systems
  • High weather tightness



Design features of the TENTAL 60 MT curtain walling

  • 60mm sightline
  • Infill between 6mm and 62mm
  • Facet solution up to +/- 10°
  • 90° corner solution
  • Full color pallette with exclusive colors



Sustainable Circular Facade

  • Designed for easy assembly and disassembly
  • Components are made with recycled materials 75/95, 75% is recycled and 95% is recyclable
  • Cradle to Cradle® certified
  • Available with Hydro CIRCAL®, aluminium made with a minimum of 75% recycled end-of-life aluminium. This aluminium has one of the lowest CO2 footprints worldwide: 1.9 kg of CO2/kg aluminium
  • Dynamic EPD available on TechDesign
Documentation
SAPA TENTAL 60 MT.pdf

Product benefits

LARGE SIZES

  • Maximum infill weight: up to 850 kg according to EN 13830
  • Maximum glazing thickness 62 mm

DIVERSITY OF APPLICATIONS

  • Different glazing installation options
  • Sloped Glazing

DIVERSITY OF FORMS

  • Multiple exterior design options
  • A full range of colors and surface treatments
  • Compatible with a full range of current window, door and sliding systems
  • Mullion - Transom construction with the benefits to use the same system for both facade and sloped glazing.
  • Mullion drained construction.

HIGH PERFORMANCE

  • Performance according to EN standard
  • Water tightness up to 1500 Pa
  • Air permeability up to 1500 Pa
  • Tested burglary resistance to RC2 / RC3
  • Acoustic insulation up to 43dB
  • Thermal Performance down to 0.52 W/m2K

More information

Technical information

You can find all technical information on TechTip.

TechTip  |  Productlines > Facades > Tental-60 (sapabuildingsystem.com)
