SAPA Door 2050 suits perfect to interior solutions or areas without insulation requirements.
The door system is based around uninsulated aluminium profiles with a section depth of 50 mm. Available with integrated or replaceable rebate sections on the frame side. The outer glazing bead is integrated in the door profile for asymmetrically installed glazing units. 2050 is also available with symmetrically installed glazing units with three different designs of glazing bead. Door leaf profiles are available for narrow and modular locks and for anti-finger trap devices. These doors can readily be combined with our system of glass walls and glazed elements, 3050.
This product is made of Hydro REDUXA® - Aluminum produced from renewable energy. Read more here
Doors and entries should be designed with enough space (clear dimension) for person traffic and to facilitate passage in a wheel chair. Applicable standards and requirements should be taken into account.
Rebate door
A = Clear Dimension
B = Frame outside dimension
C = Wall opening
D with universal hinge= 115 mm
D with lap butt hinge= 109 mm
Rounded anti-finger trap edge
A = Clear dimension
B = Frame outside dimension
Anti-finger trap with a rubber strip
A = Clear dimension
B = Frame outside dimension
Door openings should be designed without level differences from inside to outside. Sometimes a threshold is not required because of, for example, moisture or non prevailing weather conditions. When a threshold is installed, it should be as low as possible to facilitate passage. Applicable standards and requirements should be taken into account.
Door without threshold
Door with embedded threshold
Door with rebate seal against threshold
Door with strip seal
In order to reduce the risk of injury due to squeezing, we have developed a solution based on a socalled anti-finger trap edge. Applicable standards and requirements should be taken into account.
Door system 2050 with anti-finger trap edge with EPDM rubber strips.
Unprotected glazed surfaces that can be reached by persons shall be designed so as to limit the risk of injury. Such glazed surfaces shall be dimensioned so as to withstand the dynamic influence of a person. Applicable standards and requirements should be taken into account.
Functional dimensions
Glass thickness 3-33 mm
The illustration shows the different functional dimensions commonly used by the window industry and established by the MTK. The gaskets are made of EPDM rubber and are available in several versions.
Glazing
Glass thickness 3-33 mm
Certain parts of the elements can or must be filled with infill panels. It is important to consider the backing and the surface layer of the panels. If the infill panels are exposed to heavy impacts or mechanical loads, the backing should be made of durable board and the surface layer should be made of stainless or glass enamelled steel sheet.
Infill panel F2
1,5 mm Aluminium sheet
3,2 mm Board
25 mm Insulation
3,2 mm Board
1,5 mm Aluminium sheet
Infill panel F3
1,5 mm Aluminium sheet
12 mm Chipboard
20 mm Insulation
1,5 mm Aluminium
Infill panel F4
1,5 mm Aluminium sheet
20 mm Insulation
10 mm Sapa boarding
Door elements must be fixed to a stable and suitable wall structure. The choice of fixing method depends on the wall type. The number and location of fixing points depends on the size of the element.
Examples:
Frame attachment with
twist anchor
Frame attachment with
adjustable frame bushing
Frame attachment with
bolt and welded plate
Frame attachment with
screw
